제품소개
SMR-72
100A
SHR-50
Compressor
Sunbio2S의 Oil Free Air Compressor 제품군은 안정적이고 효율적인 성능을 제공합니다.
100A 카탈로그 down down-wht

Overview
Dimensions
Dimensions



Specification
Configuration Power Source Type Rated Volatage Pressure Open Flow Power Consumption Dimensions Size I.D. of Screw Thread Weight
Portable AC/DC Piston AC 110V / 220V 3kgf/cm2 190(60Hz)/170(50Hz) LPM 600W 244 x 136 x 187 mm 203.5 x 89 x M6 mm 1/4”PT inch 8.2kg
Configuration Power Source Type Rated Volatage Pressure Open Flow Power Consumption Dimensions Size I.D. of Screw Thread Weight
Portable AC/DC Piston AC 110V / 220V 7kgf/cm2 120(60Hz)/100(50Hz) LPM 600W 240 x 126 x 189 mm 203.5 x 89 x M6 mm 1/4”PT inch 7.5kg
CE EMC Certification CE LVD Certification
EN 61000-6-3:2007+A1:2011 EN IEC 61000-6-1:2019 EN IEC 61000-3-2:2019 EN 61000-3-3:2013+A1:2019 EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A2:2019+A14:2019

Oxygen Module

Booster Module

Sunbio2S
