Configuration | Power Source | Type | Rated Volatage | Pressure | Open Flow | Power Consumption | Dimensions | Size | I.D. of Screw Thread | Weight |
Portable | AC/DC | Piston | AC 110V / 220V | 3kgf/cm2 | 190(60Hz)/170(50Hz) LPM | 600W | 244 x 136 x 187 mm | 203.5 x 89 x M6 mm | 1/4”PT inch | 8.2kg |
Configuration | Power Source | Type | Rated Volatage | Pressure | Open Flow | Power Consumption | Dimensions | Size | I.D. of Screw Thread | Weight |
Portable | AC/DC | Piston | AC 110V / 220V | 7kgf/cm2 | 120(60Hz)/100(50Hz) LPM | 600W | 240 x 126 x 189 mm | 203.5 x 89 x M6 mm | 1/4”PT inch | 7.5kg |
CE EMC Certification | CE LVD Certification | |||
EN 61000-6-3:2007+A1:2011 | EN IEC 61000-6-1:2019 | EN IEC 61000-3-2:2019 | EN 61000-3-3:2013+A1:2019 | EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A2:2019+A14:2019 |
